Big Bass, Small Space
Infinity BassLink MINI delivers deep bass and takes up minimal space. Its on-board 100Wrms amplifier has been performance matched to subwoofer to deliver tight, accurate bass.
Intelligent Electronic Design for Reliable and Extraordinary Performance
The BassLink MINI employs high-pass filters and limiters that deliver exceptional at-the-limits performance.
Die-Casting Aluminum Enclosure Design
The all-die-cast aluminum enclosure design not only minimizes size but also eliminates rattles to deliver clear bass from tiny space.
Bass Volume Remote Control
Bass Volume Remote control is included to let you adjust the sound from the driver’s seat.
General Specifications
- Driver Complement
- 6″x8″ Subwoofer
- Amplifier Power
- 100Wrms; 200W Max
- Frequency Response
- 30Hz – 150Hz
- Fuse
- 15A
- Maximum Current Draw
- 13 A
- Quiescent Current Draw
- <600 mA
- Input Sensitivity
- 0.1 V – 4.0 V Low-Level Input; 0.25 V – 20V High-Level Input
- Crossover Frequency
- 50 Hz – 150 Hz
- Crossover Slope
- 12 dB/octave
- Bass Boost
- 0dB to + 12dB @ 50Hz
- Dimensions (L x W x H)
- 11-7/16″ x8-5/16″ x 3″ (289.6mm x 209.6mm x 75.0mm)
- Weight
- 8.22 lbs (3.73kg)
